7-49
Send Data: S
DM Area
D1000 000B (Number of send data items: 11) (See note 1.)
D1001 0003 (Number of Slaves)
D1002 0001 (Slave 1 address)
D1003 RUN command to Slave 1
D1004 Frequency reference to Slave 1
D1005 0002 (Slave 2 address)
D1006 RUN command to Slave 2
D1007 Frequency reference to Slave 2
D1008 0003 (Slave 3 address)
D1009 RUN command to Slave 3
D1010 Frequency reference to Slave 3
Recv data: D
DM Area
D2000 0004 (Number of Recv data items: 4) (See note 2.)
D2001 Slave 1 Inverter status
D2002 Slave 2 Inverter status
D2003 Slave 3 Inverter status
Note 1. Set the number of send data items in Hex to the number of words of D10001 through D1010
(11).
Note 2. The number of words of D2001 through D2003 (4) is written in Hex for the number of Recv
data items.
D Status Flags
Network Communications Command Execution Enabled Flag
Communications port 7 enabled setting: A20207
Protocol Macro Execution Flag
The following table describes the Protocol Macro Execution Flag.
Model Port 1 Port 2
CS-series Board 190915 191915
CS-series Unit ((n+9) words)15 ((n+10) words)15
Forced Abort Issued Flag
The following table describes the Forced Abort Issued Flag.
Model Port 1 Port 2
CS-series Board 190913 191913
CS-series Unit ((n+9) words)13 ((n+10) words)13
Communications Chapter 7
n = 1500 + 25 x unit number (words)
n = 1500 + 25 x unit number (words)
