10-17
Para
me-
ter
No.
Ref-
er-
ence
page
Chan-
ges dur-
ing
opera-
tion
Defaul
t set-
ting
Unit
of
set-
ting
Set-
ting
range
DescriptionNameReg-
ister
No.
(Hex)
13 Inverter
ready
ON: Inverter ready to
operate (with no fault
detected)
14 Fault retry ON: Fault retry
15 UV in prog-
ress
ON: Undervoltage
being monitored
16 Rotating in
reverse
direction
ON: Rotating in
reverse direction
17 Speed
search in
progress
ON: Speed search in
progress
18 Commu-
nications
output
ON: Turns commu-
nications output 1 ON.
19 PID feed-
back loss
ON: PID feedback loss
enabled.
20
(See
note.)
Frequency
reference
loss
ON: Frequency refer-
ence lost (when fre-
quency reference loss
detection in n064 is
enabled, and either
analog input or pulse
train input is set for
frequency reference
selection in n004)
21
(See
note.)
Inverter
overheating
warning
oH3
ON: Inverter overheat-
ing warning (ON when
the multi-function input
Inverter overheating
warning signal is being
input, i.e., when 0H3 is
flashing.)
Note Frequency reference loss (setting value: 20) and inverter overheating warning (setting value: 21)
can be set for 5.5-kW and 7.5-kW Inverters only.
List of Parameters Chapter 10
