10-31
Param-
eter
No.
Ref-
er-
ence
page
Changes
during
opera-
tion
Default
setting
Unit
of
set-
ting
Set-
ting
range
DescriptionNameRegis-
ter No.
(Hex)
n164 01A4 PID feedback
input block
selection
Sets the feedback input block for PID
control detection.
0: Frequency reference control termi-
nal for voltage input (0 to 10 V) is
enabled.
1: Frequency reference control termi-
nal for current input (4 to 20 mA) is
enabled.
2: Frequency reference control termi-
nal for current input (0 to 20 mA) is
enabled.
3: Multi-function analog voltage input
(0 to 10 V) is enabled.
4: Multi-function analog current input
(4 to 20 mA) is enabled.
5: Pulse train reference control termi-
nal is enabled.
* Make sure that the target value
input and feedback value input do
not overlap with each other.
0 to 5 1 0 No 6-18
n165 --- Not used --- --- --- --- --- ---
n166 01A6 Input open-
phase detec-
tion level
(See note.)
Sets the main circuit DC voltage fluc-
tuation level, as a percentage, for de-
tecting an input open phase.
200-V-class Inverters: Set 400 V as
100%.
400-V-class Inverters: Set 800 V as
100%.
If “0” is set, the input open-phase
detection function will be disabled.
Recommended setting: 7 (%)
0 to
100
1 % 0 No 6-47
n167 01A6 Input open-
phase detec-
tion time (See
note.)
Sets the input open-phase detection
time in units of seconds.
If “0” is set, the input open-phase
detection function will be disabled.
Recommended setting: 10 (s)
0 to
255
1 s 0 No 6-47
Note Available for 5.5-kW and 7.5-kW Inverters only.
List of Parameters Chapter 10
