2-5
D 3G3MV-A2055 to -A2075 (5.5 to 7.5 kW) 3-phase 200-V AC Input
3G3MV-A4055 to -A4075 (5.5 kW to 7.5 kW) 3-phase 400-V AC Input
Two, 6 dia.
Rated voltage Model 3G3MV-
Dimensions (mm)
Weight (kg)
g
D
g(g)
3-phase 200 V AC A2055 170 Approx. 4.6
3-phase 200 V AC A2075 170 Approx. 4.8
3-phase 400 V AC A4055 170 Approx. 4.8
3-phase 400 V AC A4075 170 Approx. 4.8
Design Chapter 2
