Omron SYSDRIVE 3G3MV SERIES User Manual

2-40
• Wireless devices and other equipment that generates electromagnetic waves should never
be installed in the same control panel with the Inverter.
• The DC power supply used for communications should have reinforced or double insulation.
• An Inverter control terminal has only basic insulation. More insulation is required if the termi-
nal is wired to parts people are likely to touch.
H Conforming to LVD
• Always connect the Inverter and power supply via a molded case circuit breaker
(MCCB) suitable to the Inverter for protecting the Inverter from damage that may result from short-cir-
cuiting.
• Use one MCCB per Inverter.
• Select a suitable MCCB from the following table.
• With a 400-V-class Inverter, be sure to ground to a neutral point of the power supply.
200-V Models
Inverter MCCB
Model 3G3MV- Rated current (A) Type
A2001 5
NF30 (Mitsubishi Electric)
A2002 5
()
A2004 5
A2007 10
A2015 20
A2022 20
A2037 30
A2055 50
A2075 60
AB001 5
NF30 (Mitsubishi Electric)
AB002 5
()
AB004 10
AB007 20
AB015 20
AB022 40
AB037 50
400-V Models
Inverter MCCB
Model 3G3MV- Rated current (A) Type
A4002 5
NF30 (Mitsubishi Electric)
A4004 5
()
A4007 5
A4015 10
A4022 10
A4037 20
A4055 30
A4075 30
Design Chapter 2

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
