Table B.6 Three-Phase, 200 V Class Drives Default Settings by Drive Capacity and ND/HD Setting
No. Description Unit Default Settings
− Model VZA − 20P1 20P2 20P4 20P7 21P5
C6-01 Normal/Heavy Duty − HD ND HD ND HD ND HD ND HD ND
o2-04 Drive Model Selection Hex 60 61 62 63 65
E2-11
(E4-11,
T1-02)
Motor rated power kW 0.1 0.2 0.2 0.4 0.4 0.75 0.75 1.1 1.5 2.2
b3-06 Speed Search current 1 − 1.0 1.0 1.0 1.0 1.0 1.0 0.5 0.5 0.5 0.5
b8-04 Energy saving coefficient − 481.7 356.9 356.9 288.2 288.2 223.7 223.7 196.6 169.4 156.8
C6-02 Carrier frequency − 4 7 4 7 4 7 4 7 3 7
E2-01
(E4-01,
T1-04)
Motor rated current A 0.6 1.1 1.1 1.9 1.9 3.3 3.3 4.9 6.2 8.5
E2-02
(E4-02)
Motor rated slip Hz 2.5 2.6 2.6 2.9 2.9 2.5 2.5 2.6 2.6 2.9
E2-03
(E4-03)
Motor no-load current A 0.4 0.8 0.8 1.2 1.2 1.8 1.8 2.3 2.8 3.0
E2-05
(E4-05)
Motor line-to-line resistance Ω 35.98 20.56 20.56 9.842 9.842 5.156 5.156 3.577 1.997 1.601
E2-06
(E4-06)
Motor leakage inductance % 21.6 20.1 20.1 18.2 18.2 13.8 13.8 18.5 18.5 18.4
E2-10
(E4-10)
Motor Iron Loss W 6 11 11 14 14 26 26 38 53 77
E5-01 Motor Code hex FFFF FFFF FFFF FFFF 0002 0002 0003 0003 0005 0005
L2-02
Momentary power loss ride-
through time
s 0.1 0.1 0.1 0.1 0.1 0.1 0.2 0.2 0.3 0.3
L2-03
Momentary power loss Baseblock
time
s 0.2 0.2 0.2 0.2 0.2 0.3 0.3 0.4 0.4 0.5
L2-04
Momentary power loss voltage
recovery time
s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L2-05 Uv detection voltage V dc 190 190 190 190 190 190 190 190 190 190
L3-24 Motor acceleration time s 0.178 0.178 0.178 0.178 0.178 0.142 0.142 0.142 0.166 0.145
L8-02 Overheat alarm level °C 110 110 110 110 115 115 100 100 100 100
L8-09 Ground fault selection − 0 0 0 0 0 0 0 0 0 0
L8–35 Installation Method Sel. − 0 0 0 0 0 0 0 0 0 0
L8-38
Carrier frequency reduction
selection
− 1 1 1 1 1 1 1 1 1 1
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10 10 10 10 10 10
B.5 Defaults by Drive Capacity (o2-04) and ND/HD (C6-01)
342
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
7/16/2008-13:23

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
