Table B.7 Three-Phase 400 V Class Drives Default Settings by Drive Capacity and ND/HD Setting
No. Description Unit Default Settings
− Model VZA − 40P2 40P4 40P7 41P5
C6-01 Normal/Heavy Duty − HD ND HD ND HD ND HD ND
o2-04 Drive Model Selection Hex 91 92 93 94
E2-11
(E4-11,
T1-02)
Motor rated power kW 0.2 0.4 0.4 0.75 0.75 1.5 1.5 2.2
b3-06 Speed Search current 1 − 1.0 1.0 0.5 0.5 0.5 0.5 0.5 0.5
b8-04 Energy saving coefficient − 713.8 576.4 576.4 447.4 447.4 338.8 338.8 313.6
C6-02 Carrier frequency − 3 7 3 7 3 7 3 7
E2-01
(E4-01,
T1-04)
Motor rated current A 0.6 1 1 1.6 1.6 3.1 3.1 4.2
E2-02
(E4-02)
Motor rated slip Hz 2.5 2.9 2.9 2.6 2.6 2.5 2.5 3
E2-03
(E4-03)
Motor no-load current A 0.4 0.6 0.6 0.8 0.8 1.4 1.4 1.5
E2-05
(E4-05)
Motor line-to-line resistance Ω 83.94 38.198 38.198 22.459 22.459 10.1 10.1 6.495
E2-06
(E4-06)
Motor leakage inductance % 21.9 18.2 18.2 14.3 14.3 18.3 18.3 18.7
E2-10
(E4-10)
Motor Iron Loss W 12 14 14 26 26 53 53 77
E5-01 Motor Code hex FFFF FFFF FFFF FFFF FFFF FFFF FFFF FFFF
L2-02
Momentary power loss ride-
through time
s 0.1 0.1 0.1 0.1 0.2 0.2 0.3 0.3
L2-03
Momentary power loss Baseblock
time
s 0.2 0.2 0.2 0.3 0.3 0.4 0.4 0.5
L2-04
Momentary power loss voltage
recovery time
s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L2-05 Uv detection voltage V dc 380 380 380 380 380 380 380 380
L3-24 Motor acceleration time s 0.178 0.178 0.178 0.142 0.142 0.166 0.166 0.145
L8-02 Overheat alarm level °C 110 110 110 110 110 110 90 90
L8-09 Ground fault selection − 0 0 0 0 0 0 0 0
L8-35 Installation Method Sel. − 0 0 0 0 0 0 0 0
L8-38
Carrier frequency reduction
selection
− 1 1 1 1 1 1 1 1
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10 10 10 10
B.5 Defaults by Drive Capacity (o2-04) and ND/HD (C6-01)
