No. Description Unit Setting Range
− Model VZA − 42P2 43P0 44P0 45P5
C6-01 Normal/Heavy Duty − HD ND HD ND HD ND HD ND
o2-04 Drive Model Selection − 95 96 97 99
E2-11
(E4-11,
T1-02)
Motor rated power kW 2.2 3.0 3.0 3.7 4.0 5.5 5.5 7.5
b3-06 Speed Search current 1 − 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b8-04 Energy saving coefficient − 313.6 265.7 265.7 245.8 245.8 189.5 189.5 145.38
C6-02 Carrier frequency − 3 7 3 7 3 7 3 7
E2-01
(E4-01,
T1-04)
Motor rated current A 4.2 5.7 5.7 7 7 9.8 9.8 13.38
E2-02
(E4-02)
Motor rated slip Hz 3 2.7 2.7 2.7 2.7 1.5 1.5 1.3
E2-03
(E4-03)
Motor no-load current A 1.5 1.9 1.9 2.3 2.3 2.6 2.6 4.0
E2-05
(E4-05)
Motor line-to-line resistance Ω 6.495 4.360 4.360 3.333 3.333 1.595 1.595 1.152
E2-06
(E4-06)
Motor leakage inductance % 18.7 19 19 19.3 19.3 18.2 18.2 15.5
E2-10
(E4-10)
Motor Iron Loss W 77 105 105 130 130 193 193 263
E5-01 Motor Code hex FFFF FFFF FFFF FFFF FFFF FFFF FFFF FFFF
L2-02
Momentary power loss ride-
through time
s 0.5 0.5 0.5 0.5 0.5 0.5 0.8 0.8
L2-03
Momentary power loss Baseblock
time
s 0.5 0.5 0.5 0.6 0.6 0.7 0.7 0.8
L2-04
Momentary power loss voltage
recovery time
s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L2-05 Uv detection voltage V dc 380 380 380 380 380 380 380 380
L3-24 Motor acceleration time s 0.145 0.145 0.145 0.154 0.154 0.154 0.168 0.175
L8-02 Overheat alarm level °C 100 100 100 100 100 100 110 110
L8-09 Ground fault selection − 0 0 0 0 0 0 1 1
L8-35 Installation Method Sel. − 0 0 0 0 0 0 2 2
L8-38
Carrier frequency reduction
selection
− 1 1 1 1 1 1 2 2
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10 10 10 10
B.5 Defaults by Drive Capacity (o2-04) and ND/HD (C6-01)
346
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
