003DH
Communications Error Contents
<3>
bit 0 CRC Error
bit 1 Data Length Error
bit 2 Reserved
bit 3 Parity Error
bit 4 Overrun Error
bit 5 Framing Error
bit 6 Timeout
bit 7 to bit F Reserved
003EH
Output Frequency
r/min
<4>
003FH 0.01% units
0040H to 004AH
Used for various monitors U1-. Refer to U: Monitors on page 332 for parameter details.
004BH
Drive status (U1-12)
bit 0 During Run
bit 1 During Zero Speed
bit 2 During Reverse Run
bit 3 During Fault Reset Signal Input
bit 4 During Speed Agree
bit 5 Drive Ready
bit 6 Alarm
bit 7 Fault
bit 8
During Operation Error (oPE
bit 9 During Momentary Power Loss
bit A Motor 2 selected
bit B Reserved
bit E ComRef status, NetRef status
bit F ComCtrl status, NetCtrl status
004CH to 007E
Used for various monitors U1-, U4-, U5- and U6-. Refer to U: Monitors on page 332 for parameter details.
007FH Alarm Code, Refer to Alarm Register Contents on page 374 for alarm codes.
0080H to 0097H
Used for monitors U2-, U3-. Refer to U: Monitors on page 332 for parameter details and Refer to Fault Trace
Contents on page 373 for register value descriptions.
0098H High Word of Accumulated Operation Time Monitor (U4-01)
0099H Low Word of Accumulated Operation Time Monitor (U4-01)
009AH
High Word of Cooling Fan Operation Time Monitor (U4-03)
<5>
009BH
Low Word of Cooling Fan Operation Time Monitor (U4-03)
<5>
00ABH
Drive Rated Current
<2>
00ACH
Motor Speed (Open Loop
Vector only)
r/min units
<4>
00ADH 0.01% units
00B0H Option Code
Register contains ASCII code of 3rd and 4th digit of the option card type number. Example:
Register value is 5343H for “P3” if a SI-P3 option card is installed.
00B5H
Frequency Reference After
Soft-starter
r/min units
<4>
00B6H 0.01% units
00B7H
Frequency Reference
r/min
<4>
00B8H 0.01% units
00BFH oPE Error Number
00C0H
Fault contents 3
bit 0 Reserved
bit 1 Undervoltage (Uv1)
bit 2 Control Power Supply Undervoltage (Uv2)
bit 3 Soft Charge Circuit Fault (Uv3)
bit 4 Reserved
bit 5 Ground Fault (GF)
bit 6 Overcurrent (oC)
bit 7 Overvoltage (ov)
bit 8 Heatsink Overheat (oH)
bit 9 Heatsink Overheat (oH1)
bit A Motor Overload (oL1)
bit B Drive Overload (oL2)
bit C Overtorque Detection 1 (oL3)
bit D Overtorque Detection 2 (oL4)
bit E Dynamic Braking Transistor Fault (rr)
bit F Braking Resistor Overheat (rH)
