00C1H
Fault contents 4
bit 0 External Fault at input terminal S3 (EF3)
bit 1 External Fault at input terminal S4 (EF4)
bit 2 External Fault at input terminal S5 (EF5)
bit 3 External Fault at input terminal S6 (EF6)
bit 4 Reserved
bit 5 Overspeed (oS)
bit 6 Excessive Speed Deviation (dEv)
bit 7 PG Disconnected (PGo)
bit 8 Input Phase Loss (PF)
bit 9 Output Phase Loss (LF)
bit A Motor Overheat (PTC input) (oH3)
bit B Digital Operator Connection Fault (oPr)
bit C EEPROM Write Error (Err)
bit D Motor Overheat Fault (PTC input) (oH4)
00C2H
Fault contents 5
bit 0 MEMOBUS/Modbus Communication Error (CE)
bit 1 Option Communication Error (bUS)
bit 4 Control Fault (CF)
bit 5 Reserved
bit 6 Option External Fault (EF0)
bit 7 PID Feedback Loss (FbL)
bit 8 Undertorque Detection 1 (UL3)
bit 9 Undertorque Detection 2 (UL4)
bit A High Slip Braking Overload (oL7)
bit F Hardware fault (includes oFx)
00C3H
Fault contents 6
bit 0 to 4 Reserved
bit 5 Output Current Imbalance (LF2)
bit 6 Pullout Detection (Sto)
bit 7 PG Disconnected (PGo)
bit 8 Reserved
bit A Too many speed search restarts (SEr)
bit B to F Reserved
00C4H
Fault contents 7
bit 0 PID Feedback Loss (FbH)
bit 1 External Fault 1, input terminal S1 (EF1)
bit 2 External Fault 2, input terminal S2 (EF2)
bit 3 Mechanical Weakening Detection 1 (oL5)
bit 4 Mechanical Weakening Detection 2 (UL5)
bit 5 Current Offset Fault (CoF)
bit 6 Reserved
bit 7 Reserved
bit 8 FBDs Fault (dWFL)
00C8H
Alarm contents 2
bit 0 Undervoltage (Uv)
bit 1 Overvoltage (ov)
bit 2 Heatsink Overheat (oH)
bit 3 Drive Overheat (oH2)
bit 4 Overtorque 1 (oL3)
bit 5 Overtorque 2 (oL4)
bit 6 Run Commands Input Error (EF)
bit 7 Drive Baseblock (bb)
bit 8 External Fault 3, input terminal S3 (EF3)
bit 9 External Fault 4, input terminal S4 (EF4)
bit A External Fault 5, input terminal S5 (EF5)
bit B External Fault 6, input terminal S6 (EF6)
bit C Reserved
bit D Reserved
bit E Cooling Fan Error (FAN)
bit F Overspeed (oS)
