Connector Locations
FIGURE 27
NET MGT and NET0-3 Port Locations on the SPARC T5-8 Server
Figure Legend
1
NET MGT port, for connection to Oracle ILOM management network
2
NET0-NET3 ports, for connection to 1 GbE host management network
FIGURE 28
ZFS Storage Controller
