Connector Locations
5
Service processor network management port
6
Gigabit Ethernet ports NET 0, 1, 2, 3
7
USB ports 0, 1
8
HD15 video connector
FIGURE 30
Ethernet Management Switch (Cisco Catalyst 4948 Ethernet Switch)
Figure Legend
1
Indicators and reset switch
2
Ports 1-16, 10/100/1000BASE-T Ethernet
3
Ports 17-32, 10/100/1000BASE-T Ethernet
4
Ports 33-48, 10/100/1000BASE-T Ethernet
5
CON (upper), MGT (lower)
6
Ports 45-48, 10-Gigabit Ethernet
Understanding Internal Cabling 251
