Eight-Rack Cabling
Leaf Switch Connection Cable Length
R6 U32 to Rack 5 R6-U32-P11B to R5-U1-P10A 5 meters
R6 U32 to Rack 7 R6-U32-P8B to R7-U1-P4A 5 meters
R6 U32 to Rack 8 R6-U32-P9A to R8-U1-P5A 5 meters
R6 U26 within Rack 6 R6-U26-P8A to R6-U1-P3B 3 meters
R6 U26 to Rack 1 R6-U26-P9B to R1-U1-P6B 10 meters
R6 U26 to Rack 2 R6-U26-P10A to R2-U1-P7B 10 meters
R6 U26 to Rack 3 R6-U26-P10B to R3-U1-P8B 5 meters
R6 U26 to Rack 4 R6-U26-P11A to R4-U1-P9B 5 meters
R6 U26 to Rack 5 R6-U26-P11B to R5-U1-P10B 5 meters
R6 U26 to Rack 7 R6-U26-P8B to R7-U1-P4B 5 meters
R6 U26 to Rack 8 R6-U26-P9A to R8-U1-P5B 5 meters
The following table shows the cable connections for the seventh spine switch (R7-U1) when
cabling eight full racks together.
TABLE 55
Leaf Switch Connections for the Seventh Rack in an Eight-Rack System
Leaf Switch Connection Cable Length
R7 U32 within Rack 7 R7-U32-P8A to R7-U1-P3A 3 meters
R7 U32 to Rack 1 R7-U32-P9A to R1-U1-P5A 10 meters
R7 U32 to Rack 2 R7-U32-P9B to R2-U1-P6A 10 meters
R7 U32 to Rack 3 R7-U32-P10A to R3-U1-P7A 10 meters
R7 U32 to Rack 4 R7-U32-P10B to R4-U1-P8A 10 meters
R7 U32 to Rack 5 R7-U32-P11A to R5-U1-P9A 5 meters
R7 U32 to Rack 6 R7-U32-P11B to R6-U1-P10A 5 meters
R7 U32 to Rack 8 R7-U32-P8B to R8-U1-P4A 5 meters
R7 U26 within Rack 7 R7-U26-P8A to R7-U1-P3B 3 meters
R7 U26 to Rack 1 R7-U26-P9A to R1-U1-P5B 10 meters
R7 U26 to Rack 2 R7-U26-P9B to R2-U1-P6B 10 meters
R7 U26 to Rack 3 R7-U26-P10A to R3-U1-P7B 10 meters
R7 U26 to Rack 4 R7-U26-P10B to R4-U1-P8B 10 meters
R7 U26 to Rack 5 R7-U26-P11A to R5-U1-P9B 5 meters
R7 U26 to Rack 6 R7-U26-P11B to R6-U1-P10B 5 meters
R7 U26 to Rack 8 R7-U26-P8B to R8-U1-P4B 5 meters
The following table shows the cable connections for the eighth spine switch (R8-U1) when
cabling eight full racks together.
Connecting Multiple Oracle SuperCluster T5-8 Systems 285
