Eight-Rack Cabling
TABLE 56
Leaf Switch Connections for the Eighth Rack in an Eight-Rack System
Leaf Switch Connection Cable Length
R8 U32 within Rack 8 R8-U32-P8A to R8-U1-P3A 3 meters
R8 U32 to Rack 1 R8-U32-P8B to R1-U1-P4A 10 meters
R8 U32 to Rack 2 R8-U32-P9A to R2-U1-P5A 10 meters
R8 U32 to Rack 3 R8-U32-P9B to R3-U1-P6A 10 meters
R8 U32 to Rack 4 R8-U32-P10A to R4-U1-P7A 10 meters
R8 U32 to Rack 5 R8-U32-P10B to R5-U1-P8A 5 meters
R8 U32 to Rack 6 R8-U32-P11A to R6-U1-P9A 5 meters
R8 U32 to Rack 7 R8-U32-P11B to R7-U1-P10A 5 meters
R8 U26 within Rack 8 R8-U26-P8A to R8-U1-P3B 3 meters
R8 U26 to Rack 1 R8-U26-P8B to R1-U1-P4B 10 meters
R8 U26 to Rack 2 R8-U26-P9A to R2-U1-P5B 10 meters
R8 U26 to Rack 3 R8-U26-P9B to R3-U1-P6B 10 meters
R8 U26 to Rack 4 R8-U26-P10A to R4-U1-P7B 10 meters
R8 U26 to Rack 5 R8-U26-P10B to R5-U1-P8B 5 meters
R8 U26 to Rack 6 R8-U26-P11A to R6-U1-P9B 5 meters
R8 U26 to Rack 7 R8-U26-P1B to R7-U1-P10B 5 meters
286 Oracle SuperCluster T5-8 Owner's Guide • May 2016
