Oracle SuperCluster T5-8 User Manual

Understanding the Network Requirements
Information Assigned at Manufacturing
Unit
Number
Rack Component (Front View) InfiniBand Host
Names
InfiniBand IP
Addresses
10-GbE Client
Access Host
Names
10-GbE Client
Access IP
Addresses
(Full Rack only)
36
35
Exadata Storage Server 5
(Full Rack only)
ssces5-stor 192.168.10.105 N/A N/A
34 ZFS Storage Controller 2 N/A N/A N/A N/A
33 ZFS Storage Controller 1 sscsn1-stor1 192.168.10.15 N/A N/A
32 Sun Datacenter InfiniBand Switch 36
(Leaf 2)
N/A N/A N/A N/A
31
30
29
28
Sun Disk Shelf for the ZFS Storage
Appliance
N/A N/A N/A N/A
27 Cisco Catalyst 4948 Ethernet
Management Switch
N/A N/A N/A N/A
26 Sun Datacenter InfiniBand Switch 36
(Leaf 1)
N/A N/A N/A N/A
25 ssccn2-ib8 192.168.10.80 ssccn2-tg16
ssccn2-tg15
192.168.40.32
192.168.40.31
24 ssccn2-ib7 192.168.10.70 ssccn2-tg14
ssccn2-tg13
192.168.40.30
192.168.40.29
23 ssccn2-ib6 192.168.10.60 ssccn2-tg12
ssccn2-tg11
192.168.40.28
192.168.40.27
22 ssccn2-ib5 192.168.10.50 ssccn2-tg10
ssccn2-tg9
192.168.40.26
192.168.40.25
21 ssccn2-ib4 192.168.10.40 ssccn2-tg8
ssccn2-tg7
192.168.40.24
192.168.40.23
20 ssccn2-ib3 192.168.10.30 ssccn2-tg6
ssccn2-tg5
192.168.40.22
192.168.40.21
19 ssccn2-ib2 192.168.10.20 ssccn2-tg4
ssccn2-tg3
192.168.40.20
192.168.40.19
18
SPARC T5-8 Server 2
ssccn2-ib1 192.168.10.10 ssccn2-tg2
ssccn2-tg1
192.168.40.18
192.168.40.17
17 SPARC T5-8 Server 1 ssccn1-ib8 192.168.10.79 ssccn1-tg16 192.168.40.16
