Understanding the Network Requirements
Information Assigned at Manufacturing
Unit
Number
Rack Component (Front View) InfiniBand Host
Names
InfiniBand IP
Addresses
10-GbE Client
Access Host
Names
10-GbE Client
Access IP
Addresses
ssccn1-tg15 192.168.40.15
16 ssccn1-ib7 192.168.10.69 ssccn1-tg14
ssccn1-tg13
192.168.40.14
192.168.40.13
15 ssccn1-ib6 192.168.10.59 ssccn1-tg12
ssccn1-tg11
192.168.40.12
192.168.40.11
14 ssccn1-ib5 192.168.10.49 ssccn1-tg10
ssccn1-tg9
192.168.40.10
192.168.40.9
13 ssccn1-ib4 192.168.10.39 ssccn1-tg8
ssccn1-tg7
192.168.40.8
192.168.40.7
12 ssccn1-ib3 192.168.10.29 ssccn1-tg6
ssccn1-tg5
192.168.40.6
192.168.40.5
11 ssccn1-ib2 192.168.10.19 ssccn1-tg4
ssccn1-tg3
192.168.40.4
192.168.40.3
10 ssccn1-ib1 192.168.10.9 ssccn1-tg2
ssccn1-tg1
192.168.40.2
192.168.40.1
9
8
Exadata Storage Server 4 ssces4-stor 192.168.10.104 N/A N/A
7
6
Exadata Storage Server 3 ssces3-stor 192.168.10.103 N/A N/A
5
4
Exadata Storage Server 2 ssces2-stor 192.168.10.102 N/A N/A
3
2
Exadata Storage Server 1 ssces1-stor 192.168.10.101 N/A N/A
1 Sun Datacenter InfiniBand Switch 36
(Spine)
N/A N/A N/A N/A
