OutBack Power MATE3 User Manual

Installation
18 900-0117-01-00 Rev B
Figure 8 MATE3 Connections using a HUB Communication Manager
Figure 9 MATE3 Connections for Stacked Inverters
MATE3 (Back View)
FLEXmax Charge
Controller
OutBack HUB
Communication Manager
OutBack
Inverter/Charger
CAT5 Cable
CAT5 Cable
CAT5 Cable
To program the settings for the
system on the MATE3, see the
Programming section of this manual.
MATE3 (Back View)
OutBack HUB
Communication
Manager
OutBack
Inverter/Charger
(Master)
OutBack
Inverter/Charger
(Slave)
FLEXmax Charge
Controller
CAT5 Cable
CAT5
Cable
CAT5
Cable
To program the settings for the
system on the MATE3, see the
Programming section of this manual.
CAT5
Cable
