OpAL Oxford Instruments Plasma Technology System Manual
Description
Issue 1: August 07 Page 3-24 of 46 Printed: 07 August 2009 07:42
3.6.2.4 System Link Configuration Table
NAME FUNCTION NOTES
LK1 ANALOGUE 0V TO CHASSIS
LK2 DIGITAL 0V TO ANALOGUE 0V
LK3 NON – CONTROLLER CRYO ENABLE
LK4 HEATER SNAP SWITCH BYPASS
LK5 FIT IF NO OEM CONTROLLER
LK6 A/B LK6A = NON PM140 ENDPOINT
LK6B = PM140 ENDPOINT
SEE LK7 A/B
LK7 A/B LK7A = NON PM140 ENDPOINT
LK7B = PM140 ENDPOINT
SEE LK 6 A/B
LK8 +24V DC TO RL2 COM1
LK9 +24V DC TO RL2 COM2
LK10 +24V DC TO RL6 COM1
LK11 +24V DC TO RL6 COM2
LK12 +24V DC TO RL7 COM1
LK13 +24V DC TO RL7 COM2
LK14 A/B LK14A = NON DRY PUMP FITTED
LK14B = DRY PUMP FITTED
LK15 PUMP CURRENT BYPASS
LK16 +24V DC TO RL8 COM2
LK17 NON – CONTROLLER HEATER ALARM
LK18 NON – CONTROLLER HEATER ENABLE
LK19 SPARE INT/LOCK 1 BYPASS
NOT FITTED 100/133
LK20 SPARE INT/LOCK 2 BYPASS
LK21 A/B LK21A = PURGE SWITCH NOT FITTED
LK21B = PURGE SWITCH FITTED
Table 3-4: System link configuration
3.6.2.5 System LED Monitoring Table
NAME COLOUR MONITORING
LED1 GREEN +24V DC
LED2 RED +15V DC
LED3 YELLOW -15V DC
LED4 GREEN +5V DC
LED5 RED CM COMP OK
LED6 RED PUMP CURRENT SWITCH
LED7 RED N2 PRESSURE SWITCH
LED8 RED WATER ONE
LED9 RED WATER TWO
LED10 RED WATER THREE
LED11 RED VAC STAT
LED12 RED RL10 (HOIST CONTROL)
LED13 RED HOIST
LED14 RED SPARE INTERLOCK 1
LED15 RED SPARE INTERLOCK 2
LED16 RED PUMP PURGE SWITCH
LED17 RED RL15 (MASTER/SLAVE) ACTIVE SLAVE
Table 3-5: System LED monitoring
Note that when the interlock chain is complete, all LEDs are illuminated.
