3.4.3 Control PLC (ALD valves)
The control PLC, shown in Fig 3-15 provides control of the ALD valves. The PLC
incorporates a fast microprocessor.
CPU
PLC
Connector
CAN
Interface
Analogue
PCB
Compact
flash card
B&R Analogue output
card (two channels)
B&R Analogue input
card (four channels)
PLC Base
unit
Pc2003 Digital I/O
IDC
Fig 3-15: Control plc
Description
