118 EVO Installation Guide
You can program the keypad to display up to a total of 48. Sections [101] to [196] correspond to zones 1 to 96
respectively. These zones are displayed on LED numbers 1 to 48 and are assigned values 001 to 048.
Do not assign more than one LED number to a zone. For example, you cannot assign LED number 33 to
zones 21 and 28. The rejection beep will remind you that a selected LED number is already assigned to
another section.
Every time the [CLEAR] key is pressed it will revert to the preceding step, unless entering in data in which
case it will erase the current entry.
C.0.60 Section Reset
Section [040]
This section resets zone display sections [101] to [196] to default settings. Enter [040] to perform the reset.
C.0.61 Confidential Mode
Section [009] Option [1]
In Confidential Mode all LEDs will turn off until either a button is pressed or an access code is entered.
Option [1] OFF = Disabled (default).
Option [1] ON = Enabled.
C.0.62 Exit Confidential Mode
Section [009] Option [2]
Option [2] ON = Exit Confidential Mode by entering an access code.
Option [2] OFF = Exit Confidential Mode by pressing a button (default).
Option [2] must be set to ON on UL listed systems.
Option [2] will only work if option [1] is enabled.
