Philips Efficia DFM100 - Internal Assemblies - Front Case

Internal Assemblies — Front Case 4: Repair
93
Internal Assemblies — Front Case
This section is organized into the following topics:
 LCD Display . . . . . . . . . . . . . . . . . . p. 95
 Alarm Speaker . . . . . . . . . . . . . . . . . . p. 100
 Therapy Encoder / Smart Select Knob Encoder . . . . . . . . . . . p. 101
 UI PCA . . . . . . . . . . . . . . . . . . . p. 102
 RFU Indicator . . . . . . . . . . . . . . . . . . p. 105
 Silicon Buttons . . . . . . . . . . . . . . . . . . p. 105
 Tubing Gasket Replacement . . . . . . . . . . . . . . . p. 106
CAUTIONS: Two versions UI PCAs are available for DFM100. Make sure you place the correct orders when replacing
LCD Display Assembly or UI PCA Assembly. Refer to Tab le 3 6 on page 179 and Tab le 3 7 on page 179
for more inforamtion.
Figure 59 Front Case Overview-1 R1.0
UI PCA R1.0
RFU Indicator
Therapy
Encoder
LCD Display
Assembly
R1.0
Speaker
Smart Select
Knob
