Philips Efficia DFM100 - Additional Features

1: Introduction Additional Features
6
Additional Features
The additional features of the Efficia DFM100 may include:
• Therapy Cable Collar
•Cable Straps
•Cradle
•Carry Bags
Therapy Cable Collar
When the Efficia DFM100 is used in transport or high-vibration environments, Philips strongly suggests
the device be fitted with the Therapy Cable Collar before placing the device into service. The collar adds
an extra level of security to prevent excessive wear and vibration with the Therapy port. For Efficia
DFM100 EMS devices, the Thearpy Cable Collar base comes installed from the factory.
 To Install the Therapy Cable Collar Base
1 Remove the three M3x10 flat-head screws to remove the Therapy Port Protector. See Figure 6.
Figure 6 Remove Therapy Port Protector
2 Install the three M3x10 flat-head screws to install the Therapy Cable Collar Base. See Figure 7.
Figure 7 Install Therapy Cable Collar Base
Therapy Port Protector
Therapy Cable Collar Base
