Philips Efficia DFM100 - Right (Therapy) Side; Left (Monitoring) Side

1: Introduction Tour of the Device
4
Right (Therapy) Side
The right side of the Efficia DFM100 is dedicated to administering therapy and printing. It contains a
therapy port for paddles (external or internal) or a therapy cable with multifunction electrode pads. It
also contains the printer.
Left (Monitoring) Side
The left side of the Efficia DFM100 is dedicated to monitoring key vital signs. It has ECG port and
optional EtCO
2
, SpO
2
, NBP ports.
Figure 2 Right Side View
Printer
Therapy
port
Figure 3 Left Side View
Gray CO
2
port
(optional)
White ECG port
Blue SpO
2
port
(optional)
Red NBP port
(optional)
Pouch
connector
holes
Handle
