Philips Efficia DFM100 - Pacing Problems; ECG Monitoring Problems

3: Troubleshooting Components Troubleshooting
58
Pacing Problems
ECG Monitoring Problems
TIP: When troubleshooting problems with paddles or pads, try replacing the paddles or pads first.
When troubleshooting ECG problems, try replacing the ECG cable first.
Table 15 Pacing Problems
Symptom Possible Cause Suggested Solution
Does not deliver correct current into
pacer tester or delivers no current at all
Therapy PCA failure • Run Op Check
• Inspect the Hardware Error Log
• Replace Therapy PCA
 message
 message Pacer hardware failure
Table 16 ECG Monitoring Problems
Symptom Possible Causes Suggested Solution
Flat line – no waveform, no


or  or 
message
Short in ECG cable or leads • Replace ECG cable
• Replace Measurement Module
Short in Therapy Cable • Replace Therapy Cable
• Replace Therapy Port
Processor PCA failure (if using ECG
Leads)
Replace Processor PCA
Therapy PCA failure (if using Pads) Replace Therapy PCA
Poor ECG signal quality – (noisy
trace, wandering baseline, etc.)
from signal acquired from
monitoring electrodes.
Poor skin preparation or electrode
contact
Ensure that the user is properly connecting
electrodes and preparing patient’s skin
Radio frequency interference (RFI) is
causing artefact
Relocate or turn off equipment that may be
causing RFI
Defective ECG cable or leads Replace ECG cable and leads

message
ECG cable or leads failure Replace ECG cable and leads
Internal cables failure Replace Measurement Module
Processor PCA failure Replace Processor PCA

message
Bad connection from Therapy Port
to Therapy PCA
Replace Therapy PCA High Voltage cable
Therapy Port failure Replace Therapy Port
Therapy PCA failure Replace Therapy PCA

message even though ECG cable
and leads are properly connected.
message
Poor skin preparation or electrode
contact
Ensure that the user is properly connecting
electrodes and preparing patient’s skin
Excessive motion artifact Ensure that the user reduces patient
movement

message
Wrong pads or paddles type Use only Philips-approved pads or paddles
Pads or paddles failure Replace pads or paddles
