Automated Tests
The Efficia DFM100 performs many maintenance activities independently, including three tests that run
automatically at regularly scheduled intervals while the device is off to assess operational performance and
alert you if a problem exists. Results of tests associated with critical functionality of the device are
reported through the RFU indicator and the Automated Test Summary report. Results are also reported
through Technical Alarm messages on the display when the Efficia DFM100 is turned on. Tab le 5
provides a brief explanation of the tests and lists the frequency with which each test is performed.
NOTE: Automated tests do not test the therapy cables, paddles, buttons, audio, or the display.
Automated Test Summary
An Automated Test Summary (ATS), showing the results of recent tests, may be viewed or printed as
evidence that the Efficia DFM100 is tested regularly.
 To v i ew t h e ATS :
1 Tu r n t h e T h e r a p y K n o b t o Monitor.
2 Press the Smart Select button.
3 Using the Smart Select button, select Other and press the Smart Select button.
4 Select Operational Check
and press the Smart Select button.
5 Using the Navigation buttons, select
Auto Test Summary and press the Smart Select button.
The message appears: Leaving clinical mode. Patient Monitoring will be turned off.
6 Navigate to Yes and press the Smart Select button to confirm the Exit Clinical Mode?
request.
7 Press the Print soft key to print the report.
Table 5 Automatic Self-Tests
Test Type/Frequency Components and Parameters Tested
Hourly (short) • power supplies,
• charge level of the battery,
• internal communication across all critical modules and
components
• device’s internal temperature.
Daily after midnight
(medium)
Performs an Hourly Test, plus:
• internal clock battery
• defibrillation (including low-energy internal discharges)
•pacing
•ECG
•SpO
2
(if installed)
• NBP (if installed)
•EtCO
2
(if installed)
•USB
•Printer
• 3- or 5-lead ECG cable (if connected).
Sunday early mornings
(long)
Performs a Daily Test, plus a 150-J internal discharge to exercise
the entire defibrillation circuitry.
