Philips Efficia DFM100 - Software Error Log; Hardware Error Log

Error Log Messages 3: Troubleshooting
45
Software Error Log
The Software Error Log is used by the Philips Healthcare software development team. There are no field
service actions related to the Software Error Log messages, but the Response Center may ask you to
provide the Software Error Log content. Figure 36 shows the layout of the Software Error Log.
Hardware Error Log
Figure 37 shows the layout of the Hardware Error Log.
The Info column of the Hardware Error Log contains unique numeric IDs of the messages. The numeric
ID has a format of (nn:mm), where nn is the group code, and mm is the message number within the
group. Some numeric IDs of the Therapy group have a (7:mm:ll) format. Some of the Hardware Error
Log messages along with their possible causes and suggested solutions are listed in the corresponding
subsections of the “Components Troubleshooting” section. Tab le 8 lists the groups of the Hardware
Error Log messages and pointers to the troubleshooting table for that section.
Figure 36 Software Error Log Screen


    
    
    
    
    
    



Figure 37 Hardware Error Log Screen


   
      
      
      
      
      
      



