3: Troubleshooting Operational Check
42
Figure 34 shows a sample Op Check report. The first part of the report lists test results. The second part
lists checks to be performed by the user.
Operational Check Summary
The Op Check summary lists the results from the last 60 operational checks. Test results are reported as
described in Ta ble 7.
Operational Check Summary Report
To access the Op Check summary report:
1 From the service Main Menu, navigate Other > Operational Check > Op Check summary.
2 Respond Yes to the Exit Clinical Mode?
prompt.
3 Select Export
orPrint from the Main Menu to export to a USB drive or print a copy of the report.
Figure 34 Operational Check Report
Operational Check Report Current Test Results:
General System Test: Pass Battery Test: Pass
Efficia DFM100 866199 Therapy Knob: Pass SpO2 Test: Pass
S/N: CN13300008 Charge Button: Pass NBP Test: Pass
SW Rev: 1.00.46 American English Shock Button: Pass EtCO2 Test: Pass
Audio Test: Pass Printer Test: Pass
Current Operational Check: Sync Button: Pass
17 Jan 2014 16:22 Pass Therapy Delivery Test: Pass/Pads
Leads ECG Test: Pass/ECG Cable
Last Operational Check: Pads/Paddles ECG Test: Pass/Pads
15 Jul 2013 12:34 Pass
Qty/Check List: Comments:
___ Defibrillator Inspection
___ ECG Cables/Connectors
___ Paddles/Pads
___ Monitoring Electrodes
___ Charged Battery
___ AC Power Cord
___ Printer Paper
___ SpO2 Sensor
___ EtCO2 Sensor
___ EtCO2 Sampling Line
___ NBP Cuff(s) & Tubing
___ USB Connector Inspected By:____________________
