Operational Check 3: Troubleshooting
43
Figure 35 shows a sample Op Check summary:
Figure 35 Operational Check Screen — Summary
Table 7 Operational Check Summary Results
Result RFU Indicator Definition Required Action
Pass Hourglass All tests passed None
Fail/DX Solid red X,
chirp
A critical device failure has
been detected. The failure may
prevent the delivery of a
shock, pacing, or ECG
acquisition.
Exit Op Check Summary. A Technical
Alarm indicating the problem is
displayed. Troubleshoot as described in
“Troubleshooting Process” on page 46.
Fail/CX Solid red X,
chirp.
A critical cable failure has been
detected.
Exit Op Check Summary. A Technical
Alarm indicating the failed cable is
displayed. Replace the failed cable.
Fail/BW Varies
*
* The Automated Tests continually check for a low battery condition and set the RFU Indicator
appropriately.
A battery failure was detected. Troubleshoot the battery.
Fail/D Hourglass A problem has been detected
with a component that does
not affect therapy delivery.
Exit Op Check Summary. A Technical
Alarm indicating the failed component
is displayed. Troubleshoot as described
in “Troubleshooting Process” on
page 46.


     
     
     
     
     
     
     
     
     
     
     
     
     
     


