Philips Efficia DFM100 - EtCO2 Monitoring Problems

3: Troubleshooting Components Troubleshooting
68
EtCO
2
Monitoring Problems
When troubleshooting EtCO
2
problems, it is recommended to replace the EtCO
2
sensor first. If the
problem still exists, try to replace internal tubing, and tubing of the EtCO
2
module.
If the EtCO
2
module does not start work when you connect a sampling line, try to repeat the standard
testing sequence, for example:
1 Return to the Main Menu
2 Reconnect the sampling line
3 Reenter the Service EtCO
2
screen
4 Reenter the Test screen
Table 23 EtCO
2
Monitoring Problems
Symptom Possible Causes Suggested Solution
Failure to display measurement EtCO
2
Module failure • Replace the sampling line
•Replace EtCO
2
module
Processor PCA failure Replace Processor PCA
Therapy PCA failure Replace Therapy PCA
Reading inaccurate Sampling line is blocked or
damaged
• Replace sampling line
•Replace EtCO
2
module
The EtCO
2
Module does not start
when the sampling line is connected to
the DFM100. There is no EtCO
2
waveform on the display
• Sampling line is damaged
•EtCO
2
module failure or
sensor failure
• Replace sampling line
• Run an OpCheck. If the EtCO
2
test fails,
replace the EtCO
2
Module. If the EtCO
2
test
passes, examine the sensor for dirt or foreign
objects and clean the sensor. If the problem still
exists, replace Processor PCA.
tech. alarm Sensor end of useful life Replace the sensor
tech. alarm The sensor temperature is
over 40°C
• Move sensor away from heat.
• Let the sensor cool down.
• Replace the sensor if persists
tech. alarm Hardware Error • Unplug sensor from the device for 10s and
reconnect
• Replace the sensor if persists
tech. alarm Unexpected module behavior • Unplug sensor from the device for 10s and
reconnect.
• Repeat OpCheck
• Replace the sensor if persists
tech. alarm Zero required • Perform an adapter zero
• Replace the sensor if persists
tech. alarm It may take a few seconds for
the sensor to warm up
Wait until completion
tech. alarm Sampling line may be
occluded or kinked
Check the sampling line
tech. alarm Airway Adapter not installed
or dirty
• Check the airway adapter and clean or replace
as necessary
• Replace the sensor if persists
