Device Reassembly
If your repair kit contains new accessories like shields, screws, etc., then install the new accessories and
discard the old ones.
If you do not reassemble the device correctly, it may no longer be properly sealed. This could result in
dust and moisture damage to the device. To ensure the adequate seal:
• Place all gaskets in their proper locations.
• Correctly assemble all parts that mate with gaskets (make sure the gaskets are not wrinkled, pinched,
or torn).
•Replace all screws.
• If installing several screws at a time, always install all the screws lightly, and then tighten in a
criss-cross pattern.
• Make sure that screws are not cross-threaded and firmly tightened.
Disposal
Prior to disposal, remove the external and internal batteries. Then dispose of the device in accordance
with your country’s regulations for equipment containing electronic parts.
WARNING: To avoid contaminating or infecting personnel, the environment, or other equipment, make sure you
disinfect and decontaminate the defibrillator/monitor appropriately prior to disposal.
Properly dispose of or recycle depleted batteries according to local regulations. Do not puncture,
disassemble, or incinerate batteries. Be careful not to short the battery terminals because this could result
in a fire hazard. Disposal of the device with the battery inserted presents a potential shock hazard.
Repair Tools and Equipment
 The following tools are needed to perform the procedures in this chapter:
• Torx T-8 driver only for the System-on-Module (SOM) PCA replacement.
• M3 Phillips driver (at least 100mm long).
• M4 Phillips driver (at least 100mm long).
• Therapy Port Replacement Tool (453564500151)
• Slip-joint Pliers or Adjustable open-end wrench.
• Straight-tip needle-nose pliers or tweezers.
• 75% Isopropanol Alcohol for Therapy PCA High Voltage Cable, LCD Display Cable & Fan.
• Hot Melt Glue (3M) (453564507081) only for Therapy PCA High Voltage Cable and LCD
Display Cable
• Hot Melt Glue Gun (453564507071) (3M Scotch-weld hot melt applicator 0.15kW/240V)only for
Paddle Connection Cable and LCD Display Cable.
•Flat head screw driver.
• Software Support tool for upgrades and SOM PCA repairs (see Table 35 “Software Support Tool” on
page 178 for part numbers).
• Defibrillator Discharge Tool (453564500141).
• Gloves and ESD protection for PCA handling.
