Philips Efficia DFM100 - Power and Battery

Mechanical Assemblies A: Parts and Accessories
181
Paddles
For the convenience of Philips field personnel, the 453563476991 water-resistant paddle assembly*
including labels
is available through normal parts-ordering channels.
This number is for the use of Philips personnel only. Users and non-Philips repair personnel should refer
to “Key Components” on page 184.
Mechanical Assemblies
These assemblies come with specific parts, as noted.
Replacement Mechanical Assemblies
Individual Mechanical Parts
Table 40 Replacement Mechanical Assemblies
Description 12NC
DFM100 Front Case ASSY
*
* Also order an Instruction Label set for your language option, see
“Label Sets”
on page 183.
453564489261
DFM100 Front Case ASSY 1.1* 453564587211
DFM100 Front Case ASSY 1.1 Gray* (China) 453564639901
DFM100 Rear Panel ASSY
*
453564489271
DFM100 Battery Latch ASSY 453564489311
DFM100 Battery Compartment Cover ASSY 453564489391
Table 41 Individual Mechanical Parts
Description 12NC Comment
DFM100 Handle 453564489281 set of 1
DFM100 Therapy Select Knob 453564489301 set of 5
DFM100 Silicon 2 Key 453564489341 set of 5
DFM100 Silicon 3 Key 453564489361 set of 5
DFM100 Silicon 8 Key 453564489351 set of 2
DFM100 Gasket Ring 453564489381 set of 5.3
DFM100 Navigation Wheel Knob 453564489371 set of 4
DFM100 Conductive Foam 453564489401 set of 20
DFM100 Wire Saddle 453564489411 set of 50
DFM100 Rubber Foot 453564489421 set of 40
DFM100 Power Wire Prevented Latch 453564489431 set of 10
DFM100 APPL INTFC Fixed Holder 453564489441 set of 5
DFM100 Printer Fixing Bracket 453564489451 set of 5
