1: Introduction Docking Station Installation
12
5 After placing the bedrail mount onto the docking station, pull out the latch on the docking station
and put the device onto the docking station. Loosen the latch and the DFM100 device is installed in
the docking station.
6 Use the Hex L wrench to lock the screw.
7 The installation is completed.
Figure 16 DFM100 Device Installation-5
Figure 17 DFM100 Device Installation-6
The latch is locked on the edge of the front case.
