LIFEPAK 15 Monitor/Defibrillator
Service Manual
Troubleshooting
Therapy Service Codes
Section Menu Section Contents Back Index
135
5
a204 PA_ERROR_2MS_OVERRUN (2 ms ECG sampling overrun.)
15
a208 PA_ERROR_MSG_RESYNC (Received message incomplete.)
15
a209 PA_ERROR_MSG_SIZE (Received msg size error/input buff full.)
15
a20d PA_ERROR_PACE_OVERRUN (Pacing pulse process overrun. Set current to zero.)
15
a20e PA_ERROR_PULSE_WIDTH (Pacing pulse too long.)
15
a20f PA_ERROR_A2D_INT (Internal A/D conversion timeout. Set current to zero.)
15
a210 PA_ERROR_A2D_EX (External A/D conversion timeout. Current set to zero.)
15
a211 PA_ERROR_SPI (SPI transfer timeout. Current set to zero.)
15
a212 PA_ERROR_RAM_TEST (RAM test failed. Reset Pacer Processor.)
15
a213 PA_ERROR_ROM_TEST (ROM CRC test failed.)
15
a214 PA_ERROR_CPU_TEST (Stack overrun occurred.)
15
a215 PA_ERROR_STACK_CHECK (Isolated +5 V ref. out of range.)
15
a216 PA_ERROR_V_ISO_MON (HV present when not pacing.)
15
a217 PA_ERROR_V_12V_MON (+12 V voltage out of range.)
15
a218 PA_ERROR_V_HVIS_SENSE (HV present when not pacing.)
15
Table 5.13—Initial Character a, Therapy Service Codes (TH)
Code Service Code Description
Corrective
Action Code
