Physio Control LIFEPAK 15 - Installing the Rear Case

LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Rear Case Replacement
Section Menu Section Contents Procedures Back Index
320
8
22. Install the SpO2 patent label (3207359-000) in battery well 2 (if SpO2 option is present).
23. When installing the rear case, install the following NEW labels:
~ Battery well 2 cover label, see label set (3207318-XXX), label # 9
~ Battery well 1 cover label, see label set (3207318-XXX), label # 8
~ Bluetooth label, see label set (3207318-XXX), label # 12
~ Capacitor mount cover label, see label set (3207318-XXX), label # 2
~ CO2 cover label, see label set (3207318-XXX), label # 7
~ Sys/Aux connector label, see label set (3207318-XXX), label # 3
~ FDA label, see label set (3207318-XXX), label # 5
~ Serial number label (3207131) (special order required, contact Physio-Control technical services)
 To install the rear case: (Continued) 23 steps, (Page 3 of 3)
