Physio Control LIFEPAK 15 - Page 379

LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
Front Parts Diagrams and Parts List
Section Menu Section Contents
Back
Index
381
9
Front Parts List
Table 9.4—Front Case Parts List
MIN CAT. Qty Description Notes
202253-761 21300-001038 15 SCREW-M,CS,Z,PH, NYLOCK,4-40 X .312L Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379 and Figure 9.7: Front Case parts
view 3 of 3, p. 380.
202253-764 21300-004599 4 SCREW,MACHINE,PANHEAD,NYLOK,4-40 X .500 Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379.
3006809-00 21300-001299 1 GASKET, PRINTER, SUB-D Refer to Figure 9.7: Front Case parts view 3 of
3, p. 380.
3006810-01 21300-006100 1 BRACKET, CONNECTOR, SUBD Refer to Figure 9.7: Front Case parts view 3 of
3, p. 380.
3009724-001 21330-000165 1 W16 - CABLE ASSY, RIBBON,INTERFACE PCB/CHART
RCDR
Refer to Figure 9.7: Front Case parts view 3 of
3, p. 380.
For cable interconnect view, see Figure 9.56 on
p. 478.
3009726-01 21300-001370 1 W19 - WIRE HARNESS -GROUND/PRINTER BRKT Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379 and Figure 9.7: Front Case parts
view 3 of 3, p. 380.
For cable interconnect view, see Figure 9.59 on
p. 481
