LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
Front Parts Diagrams and Parts List
Section Menu Section Contents
Back
Index
382
9
3009726-03 21300-001371 1 W17 - WIRE HARNESS-SPEAKER INTERFACE PCB Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379.
For cable interconnect view, see Figure 9.57 on
p. 479.
3011128-002 21300-003713 1 W15 - SWITCH-ROTARY Refer to Figure 9.5: Front Case parts view 1 of
3, p. 378.
3012693-00 21300-001575 1 SPRING,CLAMP, STAINLESS STEEL Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379.
3203221 21300-007358 1 A11 - DISPLAY-ACTIVE MATRIX, 8.4 ,COLOR Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379.
For cable interconnect view, see Figure 9.31 on
p. 453. Repair kit, see Display Repair Kit (MIN
3305431-013) (p. 505)
3206724-000 21330-001173 1 LENS-DISPLAY Refer to Figure 9.7: Front Case parts view 3 of
3, p. 380. Repair kit, see Front Case Repair Kit
(MIN 3305431-023) (p. 511).
3206725-XXX 21330-001174 1 SHIELD-DISPLAY Refer to Figure 9.5: Front Case parts view 1 of
3, p. 378. Repair kit, see Display Shield
Repair Kit (MIN 3305431-018) (p. 508).
3206726-001 21330-001168 1 FRAME - DISPLAY SHIELD Refer to Figure 9.5: Front Case parts view 1 of
3, p. 378. Repair kit, see Display Shield
Repair Kit (MIN 3305431-018) (p. 508).
Table 9.4—Front Case Parts List (Continued)
MIN CAT. Qty Description Notes
