LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
Front Parts Diagrams and Parts List
Section Menu Section Contents
Back
Index
383
9
3206815 21330-001236 1 A05 - PCB ASSY - INTERFACE (V1) Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379.
For cable interconnect view, see Figure 9.25 (p.
447). Repair kit, see Interface PCBA Repair
Kit, V1 (MIN 3305431-005) (p. 499).
3306367 21330-001447 1 A05 - PCB ASSY - INTERFACE (V2) Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379.
For cable interconnect view, see Figure 9.25 (p.
447). Repair kit, see Interface PCBA Repair
Kit, V2 (MIN 3305431-029) (p. 517).
3206936-002 21330-001189 1 BRACKET - LCD DISPLAY MOUNTING Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379.
3206989-000 21330-001214 1 W12 - CABLE ASSY - PRINTER CONTROL KEYPAD,
INTERFACE PCB
Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379.
For cable interconnect view, see Figure 9.52 (p.
474).
3206990-001 21330-001223 1 W18 - CABLE ASSY-FLEX,LCD,INTERFACE PCB Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379.
For cable interconnect view, see Figure 9.58 (p.
480).
3206991-003 21330-001226 1 W04 - CABLE ASSY - FLEX, SYSTEM PCB/INTERFACE
PCB
Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379.
Table 9.4—Front Case Parts List (Continued)
MIN CAT. Qty Description Notes
