Physio Control LIFEPAK 15 - Page 382

LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
Front Parts Diagrams and Parts List
Section Menu Section Contents
Back
Index
384
9
3206992-000 21330-001215 1 W06 - CABLE ASSY-BACKLIGHT INV,INTERFACE PCB Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379.
For cable interconnect view, see Figure 9.46 (p.
468).
3207030-000 21300-007051 1 KNOB-ROTARY SWITCH Refer to Figure 9.5: Front Case parts view 1 of
3, p. 378.
3207044-002 21300-007463 1 W11 - WIRE HARNESS-THERAPY, INTERNAL Refer to Figure 9.5: Front Case parts view 1 of
3, p. 378. Repair kit, see Therapy Connector
Repair Kit (MIN 3305431-009) (p. 503)
3207252-001 21300-007079 1 SHIELD, INVERTER Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379.
3207337-312 21300-007297 2 SCREW-MACH,PNH,PHH,NYLOCK,4-40, 0.312L,
WSHR,CS,ZN
Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379 and Figure 9.7: Front Case parts
view 3 of 3, p. 380
3207361-375 21300-007253 4 SCREW-CAP,SCH,REC 15IP TORX PLUS,6-
32,0.375L,SS
Refer to Figure 9.5: Front Case parts view 1 of
3, p. 378.
3207367-312 21300-007196 4 SCREW-MACH,TRH,T10 TORX,4-40,0.312L,SS Refer to Figure 9.5: Front Case parts view 1 of
3, p. 378.
3207388-001 21330-001323 1 W13 - CABLE-ASSY,MAIN KEYPAD,INTERFACE PCB Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379.
For cable interconnect view, see Figure 9.53 on
p. 475.
Table 9.4—Front Case Parts List (Continued)
MIN CAT. Qty Description Notes
