LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
Front Parts Diagrams and Parts List
Section Menu Section Contents
Back
Index
385
9
3207701-000 21300-007464 1 SEAL-THERAPY RECEPTAC Refer to Figure 9.5: Front Case parts view 1 of
3, p. 378.
3207725-002 21330-001273 1 ASSEMBLY-ENCLOSURE,FRONT Refer to Figure 9.5: Front Case parts view 1 of
3, p. 378. Repair kit, see Front Case Repair Kit
(MIN 3305431-023) (p. 511).
3207933-000 21300-007555 1 A08 - INVERTER-BACKLIGHT,DUALTUBE,12VDC,85C Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379. Repair kit, see Backlight Inverter
Repair Kit (MIN 3305431-012) (p. 505)
3208003-000 21501-002038 1 LABEL-PHYSIO-CONTROL ICON Refer to Figure 9.5: Front Case parts view 1 of
3, p. 378.
800943-09 21501-000248 1 LABEL-SYMBOL,INT'L Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379.
804234-03 21300-002394 1 SEAL-PERIMETER,CASE Refer to Figure 9.6: Front Case parts view 2 of
3, p. 379.
Table 9.4—Front Case Parts List (Continued)
MIN CAT. Qty Description Notes
