LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
OEM Optional Assemblies, Diagrams and Parts Lists
Section Menu Section Contents
Back
Index
414
9
Sp02 Internal Parts List
See Figure 9.21: NIPB, CO2, and Sp02 view 1 of 1, p. 413 for the parts listed in this table.
NIBP Parts List
See Figure 9.11: Parameter Bezel view 2 of 4 (optional CO2 and NIBP), p. 393 for NIPB external connector parts.
Table 9.8—Sp02 Part Numbers
MIN CAT. Qty Description Notes
202253-760 21300-006251 5 SCREW-M, PH, NYLOK, CS, 4-40, .250L
202253-764 21300-004599 2 SCREW, MACHINE, PANHEAD, NYLOK, 4-40 X .500
3206962-001 21300-007550 1 BRACKET - MOUNTING, Sp02 MODULE
3207000-004 21330-001321 1 W21 - ASSY-CABLE, FLEX, Sp02, OEM, PCB
3207034-002 21300-007710 1 A16 - MODULE-OEM, PULSE OXIMETER, MX-1
Table 9.9—NIBP Part Numbers
MIN CAT. Qty Description Notes
202253-760 21300-006251 4 SCREW-M, PH, NYLOK, CS, 4-40, .250L Refer to NIPB, CO2, and Sp02 (p. 413)
3010805-000 21300-001416 1 SOCKET RETAINER CLIP -10PIN Refer to NIPB, CO2, and Sp02 (p. 413)
3012181-00 21330-000235 1 W27 - CABLE ASSY-RIBBON, NIBP/OEM
PCB
Refer to NIPB, CO2, and Sp02 (p. 413). For cable
interconnect view, see Figure 9.64 (p. 486).
