LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
OEM Optional Assemblies, Diagrams and Parts Lists
Section Menu Section Contents
Back
Index
415
9
CO2 Parts List
See Figure 9.11: Parameter Bezel view 2 of 4 (optional CO2 and NIBP), p. 393 for CO2 external connector parts.
3317965-002 1 A21 Module - NIBP, MaxIQ V5.2, RoHS Refer to NIPB, CO2, and Sp02 (p. 413). For cable
interconnect view, see Figure 9.38 (p. 460). Repair
kit, Paddle Retainer Repair Kit (MIN 3305431-017)
(p. 508).
3206268-011 21300-007912 1 A21 - NIBP ND+ MODULE, DSP V4.0
AND SAFETY CPU V2.0
Refer to NIPB, CO2, and Sp02 (p. 413). For cable
interconnect view, see Figure 9.38 (p. 460). Repair
kit, Paddle Retainer Repair Kit (MIN 3305431-017)
(p. 508).
Table 9.10—CO2 Part Numbers
MIN CAT. Qty Description Notes
202253-760 21300-006251 4 SCREW-M, PH, NYLOK, CS, 4-40, .250L Refer to NIPB, CO2, and Sp02 (p. 413).
3012140-002 21300-001557 1 EXHAUST TUBING - CO2 Refer to NIPB, CO2, and Sp02 (p. 413).
3012140-006 21300-006948 1 A23 - MODULE, CO2, MINI Refer to NIPB, CO2, and Sp02 (p. 413). For cable
interconnect view, see Figure 9.40 (p. 462).
Table 9.9—NIBP Part Numbers
MIN CAT. Qty Description Notes
