LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
Connection Diagrams for Assemblies, Control Boards, Cables, and
Connectors
Section Menu Section Contents
Back
Index
489
9
Invasive Pressure Assembly
Figure 9.67—Diagram for item W33
System PCB (p. 444)
Refer to Figure 9.12: Parameter Bezel view 3 of 4
(optional invasive pressure), p. 394.
See MIN 3200466-01 in table for parts information.
