The page includes the following fields:
Object Description
• Trunk
Display the current trunk ID.
• Port
Display the current port number.
• PartnerSysId
The system ID of link partner. This field would be updated when the port receives
LACP PDU from link partner.
• PnKey
Port key of partner. This field would be updated when the port receives LACP
PDU from link partner.
• AtKey
Port key of actor. The key is designed to be the same as trunk ID.
• Sel
LACP selection logic status of the port. “S” means selected, “U” means
unselected, and “D” means standby.
• Mux
LACP mux state machine status of the port. “DETACH” means the port is in
detach state, “WAIT” means waiting state, “ATTACH” means attach state,
“CLLCT” means collecting state, “DSTRBT” means distributing state.
• Receiv
LACP receive state machine status of the port. “INIT” means the port is in
initialize state, “PORTds” means port disabled state, “EXPR” means expired
state, “LACPds” means LACP disabled state, “DFLT” means defaulted state,
“CRRNT” means current state.
• PrdTx
LACP periodic transmission state machine status of the port. “no PRD” means
the port is in no periodic state, “FstPRD” means fast periodic state, “SlwPRD”
means slow periodic state, “PrdTX” means periodic TX state.
• AtState
The actor state field of LACP PDU description. The field from left to right
describes: “LACP_Activity”, “LACP_Timeout”, “Aggregation”, “Synchronization”,
“Collecting”, “Distributing”, “Defaulted”, and “Expired”. The contents could be true
or false. If the contents are false, the web shows “_”; if the contents are true, the
web shows “A”, “T”, “G”, “S”, “C”, “D”, “F” and “E” for each content respectively.
• PnState
The partner state field of LACP PDU description. The field from left to right
describes: “LACP_Activity”, “LACP_Timeout”, “Aggregation”, “Synchronization”,
“Collecting”, “Distributing”, “Defaulted”, and “Expired”. The contents could be true
or false. If the contents are false, the web shows “_”; if the contents are true, the
web shows “A”, “T”, “G”, “S”, “C”, “D”, “F” and “E” for each content respectively.
