User
’s M
anual of WGSW
-28040 / 28040P
91
Figure 4-5-4
Port
VLAN S
tatus page screenshot
The page
includes the fol
lowing field
s:
Object
Description
•
Port
The swit
ch port numbe
r of the logica
l port.
•
PVID
Display the current PVID.
•
Accept Frame T
ype
Displays the
current accept f
rame type.
90
92
