Page #653 background imageLoading...
Page #653 background image
3 Diagnostics, Troubleshooting and Testing
19
Meritor WABCO Maintenance Manual MM-0112 (Revised 07-05)
Blink Code Identification
Use the following information to identify the blink code:
First Digit (Type of Fault)
Second Digit —
Specific Location of Fault
1 No faults 1 No faults
2 ABS modulator valve
3 Too much sensor gap
4 Sensor short or open
5 Sensor signal erratic/tire size
6 Tooth wheel
1 Right front steer axle (curb side)
2 Left front steer axle (driver’s side)
3 Right rear drive axle (curb side)
4 Left rear drive axle (driver’s side)
5 Right rear/additional axle (curb side)
1
6 Left rear/additional axle (driver’s side)
1
7 System function
2
1 J1939 datalink
2 ATC valve
3 Retarder relay (third brake)
4 ABS indicator lamp
5 ATC configuration
6 RSC valve
8 ECU 1 Low power supply
2 High power supply
3 Internal fault
4 System configuration error
5 Ground
6 RSC accelerometer
1
Tandem, lift, tag or pusher axle depending upon the type of suspension
2
If this code continues after all repairs have been made — or if you receive a code for a
component that is not installed on the vehicle — it may be necessary to reconfigure the ECU.
Refer to Appendix III. TOOLBOX™ Software may also be used to reconfigure the ECU (refer to
Appendix III). Contact ArvinMeritor’s Customer Service Center at 800-535-5560 for
reconfiguration information.
