FAULT CODE MANUAL Created on 00-04-25 15:30
- 19 -
14. Fault codes, TECU Voith 863,3 retarders and transmission (MID 130)
MID (P)PID/SID FMI Seriousness Component/function Display text
130 PID 40 2 - Hand brake sensor Retarder switches
130 PID 65 2 - Foot brake sensor Brake pedal switch
130 PID 92 2 - Software Engine load, %
130 PID 93 2 - CAN Engine torque
130 PID 93 14 - CAN Engine torque
130 PID 124 1 - Low oil level Transm. oil level
130 PID 152 14 - ECU-Reset No. of ECU resets
130 PID 158 1 - Power supply Battery potential
130 PID 162 2 - Gear selector switch Gear selected
130 PID 177 0 - Temperature sensor Transm. oil temp.
130 PID 177 5 - Temperature sensor Transm. oil temp.
130 PID 177 6 - Temperature sensor Transm. oil temp.
130 PID 177 13 - Temperature sensor Transm. oil temp.
130 PID 177 14 - Temperature sensor Transm. oil temp.
130 PID 190 11 - Engine speed Engine speed
130 PID 191 11 - Output speed Output shaft speed
130 PID 234 14 - Frequency output Software no.
130 SID 1 12 - Control solenoid valve turbine brake Solenoid valve #1
130 SID 4 12 - Control solenoid valve 4 speed clutch Solenoid valve #4
130 SID 6 12 - Solenoid valve converter brake Solenoid valve #6
130 SID 7 12 - Control solenoid valve pump brake Lockup sol.valve
130 SID 8 12 - Control solenoid valve input clutch Forward sol. valve
130 SID 17 11 - Turbine speed Turbine speed
130 SID 52 13 - Pressure rise fault Hydraulic system
130 SID 153 14 - -
130 SID 153 14 - - -
130 SID 153 14 - - -
130 SID 153 14 - - -
130 SID 153 14 - - -
130 SID 221 14 - Power supply for brake sensors Int sensor supply
130 SID 231 9 - CAN SAE J1939 data link
130 SID 233 2 - Message from safety computer Controller #2
130 SID 238 14 - Pushbutton switch lightning Diagnostic lamp RED
130 SID 239 14 - Central warning light Diag. lamp AMBER
130 SID 240 14 - Software Program memory
