PREVOST X3-45 Multiplex User Manual

SECTION 01: ENGINE
PA1562
7
1.2 ENGINE OVERVIEW
NOTE
For maintenance on or repair of engine components or engine-related components, please refer to
Volvo Trucks Canada or Volvo Trucks North America Web Site under: Parts & Service, purchase
engine literature, D13F engine.
FIGURE 2: D13F ENGINE, TURBO SIDE (TYPICAL)
1. EGR Valve 8. Coolant Pump
2. Aftertreatment Fuel Injector 9. Oil Filters
3. Exhaust Manifold 10. EGR Cooler
4. Valve Cover 11. Oil Pan
5. Engine Preheater Element 12. Starter Motor
6. Thermostat Cover 13. Turbocharger
7. Belt Tensioner

PREVOST X3-45 Multiplex Specifications

General

Length	45 ft
Width	102 in
Engine	Volvo D13
Horsepower	500 hp
GVWR	54, 000 lbs
Height	146 in
Sleeping Capacity	Varies based on floor plan
Water Capacity	Varies based on floor plan
