Tools Required
Press
Retaining ring pliers
7/8" Deep well socket
Input Shaft Replacement
1. Remove the retaining ring (25), nearest the engine
drive end, from the shaft.
Remove woodruf key, if equipped.
Remove retaining
ring
2. Press the input shaft (28) from the ball bearing (26)
applying pressure to the engine drive end of the
input shaft.
Remove the second retaining ring (25) and replace it
in the same groove in the new input shaft, sheared
edge out.
Press shaft from
bearing
Retaining ring
pliers
Press
3. Press the new input shaft (28) into the ball bearing
(26) from the small splined end, until it bottoms on
the retaining ring.
Press ball bearing
onto input shaft
7/8" Deep well
socket
Press
4. Install the retaining ring (25) onto the input shaft
with the sheared edge away from the bearing.
Make sure it is properly seated in its groove.
Install retaining
ring
Retaining ring
pliers

PREVOST X3-45 Multiplex Specifications

General

Length	45 ft
Width	102 in
Engine	Volvo D13
Horsepower	500 hp
GVWR	54, 000 lbs
Height	146 in
Sleeping Capacity	Varies based on floor plan
Water Capacity	Varies based on floor plan
