PREVOST X3-45 Multiplex User Manual

24. Install the spring (7).Install spring
25. Install a new o-ring (8) onto the plug (9).Install o-ring
26. Lightly grease the o-ring (8) and plug (9) threads.
Install into housing, and torque to 20 lbf•ft. (27 N•M)
Install plug &
o-ring
1 1/4" Socket
Torque wrench
27. Install the woodruf key into the new input shaft, if
removed during input shaft replacement.
Install woodruf
key if removed

PREVOST X3-45 Multiplex Specifications

General

Length	45 ft
Width	102 in
Engine	Volvo D13
Horsepower	500 hp
GVWR	54, 000 lbs
Height	146 in
Sleeping Capacity	Varies based on floor plan
Water Capacity	Varies based on floor plan
