Repair and Testing Instructions for T1 Page 12
Alternator 0120 689 552 Edition 001
All rights rest with Robert Bosch Corp, including patent rights. All rights of use of reproduction and publication rest with R. B. Corp.
UA/ASV 04.12.98 T1ALTFinal.DOC
7 Tools, Test Equipment Lubricants and Adhesives
7.1 Test Equipment
Description Bosch Number
Alternator Test Bench Commercially Available
Internal Short-Circuit Tester (Flash Tester) KDAW 9978 0 986 619 110
Universal Multi-Meter MMD 302 0 684 500 302
Alternator Tester WPG 012.00 0 684 201 200
7.2 Special Tools
Description Bosch Number
Arbor Press Commercially Available
Soldering Iron Commercially Available
Universal Bearing Puller Commercially Available
V-Block
Note: 2 Required
Commercially Available
14mm Hex, 1/2" Drive Socket Commercially Available
Clamping Support KDAW 9999 0 986 619 362
Die Spigot for Arbor Press (Used with KDLJ 6011, KDLJ 6012,
KDLJ 6015)
KDLJ 6010 0 986 618 124
Bearing Remover KDLJ 6009 0 986 618 121
Press Tool for Roller Bearing KDLJ 6021 0 986 618 139
Bearing and Seal Installer KDLJ 6011 0 986 618 125
Collector Ring Installer KDLJ 6012 0 986 618 126
Drive End Shield Support Ring for Rotor Pressing KDLJ 6013 0 986 618 127
Press Tool - Spacer Ring, Roller Bearing Inner Race and Collector
Rings
KDLJ 6018 0 986 618 134
Alignment Pin - Drive End Shield and Collector Ring End Shield KDLJ 6014 0 986 618 128
Removal Tool - Sliding Bushing KDLJ 6015 0 986 618 129
Holding Tool - Sliding Bushing KDLJ 6016 0 986 618 130
Inner Bearing Race Removal Tool KDAW 9996 0 986 619 269
Puller Receiver Cup KDAW 9995/0/1 0 986 619 214
Threaded Pin with Cone KDAW 9995/14 0 986 619 250
Bearing Puller Spring Collet KDAW 9995/6 0 986 619 233
Feeler Gauge 0.15 … 0.6 mm (.005 … .024 in)
Note: 4 required
KDZV 7399 0 986 618 378
Dial Indicator EFAW 7 1 687 233 011
Magnetic Indicator Stand T-M 1 4 851 601 124
